68mm x 550mm Self Install Ground Screw

68mm x 550mm Self Install Ground Screw

Not sure how many ground screws you need?
Try our calculator
(4 customer reviews)

£17.49 ex. VAT

Product code: GS-68x550

In stock

length

550mm

install range

100mm

diameter

68mm

load capacity

230kg

material

Galvanised Steel

wall thickness

1.8mm

The 550mm self-install ground screw is quick and easy to install with minimal impact on the environment. It is ideal to create foundations for simple structures such as shed bases and decking and is compatible with all of our self installation bracket options.

Key Highlights

  1. Perfect for a variety of domestic & commercial applications
  2. Hassle-free installation with our manual or ratchet tool
  3. Hot Dip Galvanised Steel with BS EN 1461:2009 compliance
  4. CE approved with a 20-year product guarantee
  5. Compatible with all bracket systems

Load capabilities & recommended install range:

  • Maximum Compression Load Capability – 230kg (2.3kn)
  • Maximum Tension Load Capability – 170kg (1.7kn)
  • Maximum Horizontal Load Capability – 50kg (0.5kn)
  • Ground level – 100mm above ground level

Benefits of Ground Screws

  • Quick & Simple

    Easy to install yourself in a matter of minutes, enabling you to get your project out of the ground straight away without any waiting, any time of the year.

  • Less mess, less cost

    A quick and clean alternative to messy concrete, no digging, no waste, no costly skips. Save money on the total cost of installing foundations.

  • Designed to last

    Our ground screws are fully galvanised to protect against rusting. For added peace of mind, they are CE certified with our 20-year product guarantee and are BS EN 1461:2009 compliant.

  • Immediately load bearable

    Suitable for a wide range of structures, our ground screws are immediately load bearing, so as soon as they are installed you can start building.

  • Permanent or temporary structures

    Suitable for permanent or temporary structures and easily removable with no lasting pollutants left behind

  • Environmentally friendly

    Reduced CO2 from pouring concrete. Helps protect habitats and prevent damage to tree root systems

  • No Heavy Equipment

    Purchase your hand ratchet tool for quick and easy installation due to no heavy equipment required

  • Lightweight & Compact

    Using ground screws eliminates any access issues - Our ground screws, bracket systems and tools can all be carried by hand.

  • Reduced Disruption

    The DIY approach minimises disruptions to your property, as it often involves less noise, debris, and disturbance compared to traditional foundation construction.

4 reviews for 68mm x 550mm Self Install Ground Screw

  1. groundscrewcen

    Great product! Easy to install.

  2. Jamie Davies

    Used the trial kit, and it gave me confidence to order 16 screws for my garden room project. They quickly and I installed them with the hand-tool within 3 hours. Job sorted.

  3. Rosemary Hayward

    Very straightforward and easy to order. Help to select correct fittings was given. Delivery was ahead of time and all correct. Installation was straightforward using the rented ratchet tool. An excellent product, good to install and does the job 👍👍 In no time at all my workshop/studio was on the way to completion. Would highly recommend using ground screws and would certainly use again.

  4. Jamie Wilson

    Fantastic service from GSC – fast delivery, easy to install onsite and it all worked out much cheaper than using a concrete pad. Next project I’m going to use GSC for sure.
